Product Description
plastic hiflow ring packing is one kind of high performance random tower packing. The open structure and resistance to nesting provide maximum protection against fouling and plugging.Hiflow ring is very similar with Norpak by Norddeutsche seekabelwerk, but its vertical bar is interlacely distribute. Furthermore, 6 strengthen muscles in the middle of circle enhance its rigidity and intensity. Additional properties of plastic?hiflow ring packing are high capacity gas and liquid flow rates, extremely low pressure drop, very low wall flow, and low sensitivity to pollution and fouling. plastic hiflow rings are widely used in Absorbers, Liquied/Liquid Extraction, Degassing, Heat Transfer, Water Treatment,etc.
Plastic Hiflow Ring‘s Technical Data:
Type/size | Bulk Density | Surface Area | Void fraction |
mm | Kg/m? | m?/m? | % |
15*7 | 80 | 33 | 91 |
25*7 | 79 | 214 | 92 |
38*1 | 58 | 150 | 94 |
50*0 | 54 | 110 | 94 |
50*3 | 52 | 95 | 94 |
50*6 | 49 | 90 | 94 |
90*7 | 33 | 76 | 96 |
Note: Weight data refer to Polypropylene
Properties of Plastic Material:
Material | PE | PP | RPP | PVC | CPVC | PVDF |
Density g/cm3 | 0.94-0.96 | 0.89-0.9 | 0.92-0.9 | 1.32-1.44 | 1.50-1.54 | 1.75-1.78 |
Using Temperature °C | ≤90 | ≤100 | ≤120 | ≤60 | ≤90 | ≤150 |
Chemical Corrosion Resistance % | Anti-corosion | |||||
Tensile Strength N/mm2 | >6.0 | >6.0 | >7.0 | >6.0 | >8.0 | >10.0 |
Our advantage:
1.More than 10years manufacturing exper experience.
2.ISO9001:2008 certification available.
3.Reasonale price and good service.
4.Free Sample is available, shipping and taxes paid by buyer.
